How Often Shall We Maintenance On My Roof Panel Roll Forming Machine?

All of Xiamen Bogong Machinery’s portable roof panel roll forming machines have common maintenance procedures, it based on how often you run your machines. If you use your machines at a normal operating duty, try to take any maintenance actions two or three times a week, checking it over at least once a week. The more often you maintain and inspect your machine, the less time it will take you overall to keep up with routine cleaning, and other items.

Please note that not every roof panel roll forming machine will use this same specific timing or instructions, but the below recommendations are based on the SSQ II™ MultiPro Roof Panel Machine manual:

Every 30 hours of operation - Lubricate the three main drive gears with Open Gear Spray Lubricant (recommended).

Every 40 hours of operation - Lubricate the chains with dry motorcycle chain lube or equivalent.

Daily - Clean and lubricate Top Blades, Bottom Dies and Male/Female Dies of the Shear Blade with Spray Lube so they last longer. More should be added as needed before the cut edges begin to deteriorate, or whenever cutting surfaces look dry.

Weekly - Check hydraulic oil fluid levels, otherwise it will degrade if it remains stagnate in the system for too long. The hydraulic system operates the Shear and Drive assemblies, so it must be properly maintained to ensure trouble-free operation and longevity.

The fluid level should be about 6” below the top of the filler neck (refer to your machine specific manual for oil level specifications). Also, note the color and condition of the fluid. Good and clean fluid should be clear in color.

Yearly - Every year it’s recommended to change the hydraulic system oil and filter, especially if portable roll forming machinery is used outdoors and exposed to the elements. Change the fluid more frequently if the machine is constantly operating in a dusty environment or if the fluid becomes contaminated. The filter should be replaced when the red Replacement Indicator sticks up.

Portable Roof Panel Roll Forming Machine Maintenance: Tips and Guidelines

For these roof panel machine maintenance guidelines, we’re going to follow the SSQ II MultiPro Roof Panel Machine manual, but general maintenance actions are similar for all of Xiamen Bogong Machinery’s roof panel machines.

Tools you may need for maintenance on your steel roof panel machine may include: a wrench or socket, screwdriver, or hex key, but refer to your specific machine’s manual for detailed instructions and tools needed. Also in your manual are recommended lubricants to use when cleaning machine parts.

Remember, before doing any maintenance on your machine:

1. roof panel machine manual Read and understand the machine manual before attempting to operate the machine.

2. Always keep guards, covers, and lids mounted to the machine during operation.

3. Observe and obey all safety and warning signs affixed to the machine.

4. Always adhere to and follow all local and national safety codes concerning the loading and unloading of reeled coils.

5. Use only properly rated devices for lifting reeled coils into or out of the reel stand assembly.

6. Do not wear loose clothing, jewelry, etc. that could become entangled in moving parts of the machine when in operation.

7. Stop the machine and disconnect power before attempting to make any adjustments, perform any maintenance or changeover procedures.

Follow safe handling of the lubricants according to the SDS.

It is the responsibility of the end user to take into consideration safe instructions for loading the material, safe access to lubricating parts, changing the roller sets and maintaining the machinery. Machinery is to be operated and maintained by qualified personnel.
